DJI Matrice 4T Worry-Free Plus Combo

DJI
Flight time
up to 49 min
Max payload
200 g
Link FCC/CE
up to 25 / 12 km

Price on request · Available to order

Description

Matrice 4T supports inspections with visible cameras, thermal imaging and a rangefinder. The team selects observation tools for each area and compares the camera data. Worry-Free Plus Combo identifies a package whose contents must be distinguished from aircraft specifications.

Specifications

Aircraft and installed systems

Max flight time
49 minStandard propellers, no payload, approx. 9 m/s, no wind, to 0% battery
Max payload
200 g
Transmission range
25 / 12 kmFCC / CE; unobstructed and interference-free; one-way non-return flight
Max horizontal speed
21 m/sSea level, no wind; forward; backward 18 and sideways 19 m/s
Takeoff weight
1219 gBattery, standard propellers and microSD; actual weight can vary
Unfolded dimensions
307 × 387.5 × 149.5 mmL×W×H; propellers excluded
Folded dimensions
260.6 × 113.7 × 138.4 mmL×W×H; propellers excluded
Takeoff weight with low-noise propellers
1229 g
Flight time with low-noise propellers
46 minSame test conditions as maximum flight time
Max hover time
42 / 39 minStandard / low-noise propellers; no wind, sea level, 100-0%
Max takeoff weight
1420 / 1430 gStandard / low-noise propellers
Max wind resistance
12 m/sDuring takeoff and landing
Operating temperature
-10 to 40 °C
4T cameras
48 MP / 48 MP / 48 MPWide 1/1.3; medium tele 1/1.3; tele 1/1.5-inch CMOS
Thermal imager
640 × 512Uncooled VOx; native resolution, 30 Hz
Thermal sensitivity
≤50 mKAt f/1.0
Thermal measurement range
-20 to 150 / 0 to 550 °CHigh / low gain
Laser rangefinder
1800 m1 Hz; 20% target reflectivity; rain/fog can reduce performance
Sensing type
Omnidirectional binocular vision + 3D infrared sensorInfrared sensor below aircraft
Flight battery
Li-ion 4S
Battery capacity
6741 mAh
Standard battery voltage
14.76 V
Battery energy
99.5 Wh
